Instruction Manual for AS380 Series Elevator Integrated Drive Controller
85
L5 down level-4 forced deceleration switch status
L6 up level-1 forced deceleration switch status
L7 up level-2 forced deceleration switch status
L8 up level-3 forced deceleration switch status
L9 up level-4 forced deceleration switch status
L10 up limit switch status
L11 up leveling switch status
L12 down leveling switch status
L13 firefight return/ firemen operation switch
L14 motor overheat signal
LED 06
L1
～
L18
Corresponding input point：X0
～
X17 status
Main board input
point on-off, light
on means the
external input point
is connected
LED 07
L1 Door lock relay ( X17 value setting- light on if no
switch-on/off very often)
The hoist way self-
study startup
condition. All these
9 light on means
peripheral signal is
normal, the hoist
way self-study is
on
L2 main contactor contact input signal ( contactor no
adhesion, light on)
L3 band brake contactor contact input signal ( contactor no
adhesion, light on)
L4 band brake switch
L5 motor overheat
L6 up limit switch( compound) status signal
L7 down limit switch( compound) status signal
L8 door close limit switch signal ( front and rear door)
L9 light on if startup internally is good.
L10 self-study command 1 The internal status
of hoist way
self-study, all six
light on one by one
when the self-study
run.
L11 next level forced slowdown status
L12 down leveling switch status
L13 up leveling switch status
L14 self-study command 2
L15 self-study startup
