167
DEFRNLIT EN
0478 131 9965 A - EN
Unscrew the screws (1) and remove.
Fold the upper housing (1) rearwards.
Detach the connector (1) (battery).
Remove cable (1) and cable (2) from the
cable guides and remove the battery (3).
Risk of injury!
Do not cut cables at the battery.
Risk of short circuit!
Always disconnect the cables and
remove together with the battery.
Risk of injury!
Prevent damage to the battery.
21. Transport
Risk of injury!
Before transporting, carefully read
the section "For your safety" (Ö 6.),
particularly the subsection
"Transporting the machine" (Ö 6.5),
and follow all safety instructions –
always activate the disabling
device. (Ö 5.2)
