Storz DUOLITH SD1 - 3.1 Overview of the entire system

3-2
17 363 02 0320
System description
3.1 Overview of the entire system
The concept of the DUOLITH
®
SD1 device is modular.
Depending on its level of expansion, the device includes the following modules:
1 CONTROL module with touch screen
1.1 CONTROL module with integrated ultrasound unit*
2 R-SW module
3 F-SW module
1.1
2
3
1
Fig. 3-1 Front complete
* Optionally available with colour doppler process.
