System description
The R-SW handpiece is also updated immediately after it is connected when there has
been a software update of the system.
Depending on the therapy to be performed, the handpiece can be equipped with dif-
ferent shock transmitters:
For operation of the handpiece R-SW using the embedded display, using the shock
transmitters as well as changing the shock transmitters please read the
separate Opera-
ting Manual Of the r-sW handpieCe.
3.7.3 V-ACTOR handpiece
The V-ACTOR is a “vibration therapy” handpiece and can be used as an optional ac-
cessory with the DUOLITH/CELLACTOR and MP200/D-ACTOR 200 group of devices for
radial and focused shock wave therapy and/or for planar pulses and pressure pulses.
By using this handpiece, it is possible to treat soft tissues using high-frequency pulses.
1 Trigger button
2 Shock transmitter
2
1
Fig. 3-31 V-ACTOR
Depending on the therapy to be performed, the handpiece can be equipped with one
of the following three shock transmitter heads:
– with the V-ACTOR spherical shock transmitter 10 mm (V10) Fig. 3-32/1
– with the V-ACTOR shock transmitter 25 mm (V25) Fig. 3-32/2
– with the V-ACTOR shock transmitter 40 mm (V40) Fig. 3-32/3
1 2
3
Fig. 3-32 V-ACTOR shock transmitters
For description of the handpiece, changing of the transmitters as well as mounting
the stand-off device please refer to the
separate Operating Manual Of the v-aCtOr
handpieCe.
