4-32
17 364 02 0320
Operation
• To send the data of the doctor’s surgery EDP system, press
.
The DUOLITH SD1 sends the supplemented data back to the doctor’s surgery system.
Fig. 4-36 GDT transfer
4.5.21 Visible Body - Anatomy Atlas
Visible Body is an interactive 3D atlas of the human body allowing all 3D models and
animations of the body systems and regions of humans to be represented. Treatment
regions can be marked by the operator for the patient records and the image can be
saved subsequently as a screenshot.
NOTE
The gures in this chapter are examples. The described actions work in all represen-
tations.
