4-8
17 364 02 0320
Operation
Treatment OFF.
Press to start treatment.
Treatment ON.
Press to stop treatment.
Table 4-4 Setting parameters VACU ACTOR
Explanation of terms
Mode VI
The suction cup creates an interaction of vacuum and positive pressure with the adju-
sted frequency.
Mode VC
The suction cup creates a negative pressure. It pulsates between vacuum and ventila-
tion by different frequency settings.
Sizes of suction cups
Size XS
Size S
Size M
Size L
4.4.3 Contact intensity and Skin Touch display
You can track the contact intensity on a scale during the R-SW treatment.
The indicator of the intensity on the scale will begin to move as soon as you touch
the treatment zone with the R-SW shock transmitter. When the cursor is in the green
range, the contact intensity for the treatment corresponds to the recommended
intensity for the treatment.
You will also see whether the Skin Touch function is active.
Fig. 4-9 Contact intensity display
