4.4 Displays and symbols
The DUOLITH
®
SD1 is operated using a colour TFT LCD monitor with touch screen
function and a graphical user interface.
The user interface of the DUOLITH
®
SD1 is divided into various areas for displaying
different information.
Module selection
Parameter
selection
Counter
display
Contact
pressure
Menu bar: Monitor
Monitor
Menu bar: Info & settings
Language
Date / time
Fig. 4-4 Structure of the user interface
