System description
Fig. 3-14 Positioning handle
• Lock the transport wheels once again.
3.5 Description of the Control module
3.5.1 Control and functional elements
The individual modules of the device are operated using the control module by means
of a colour TFT LCD monitor with touch screen.
The control module has a standby on/off switch with a check lamp (Fig. 3-18/2).
All the connected, USB-controlled additional elements are switched on and off simul-
taneously using this switch.
1
2
1 Monitor with touch screen
2 Standby on/off switch
Fig. 3-15 Front complete
