Storz DUOLITH SD1 - 4.7 Operation with the Module R-SW

4-46
17 364 02 0320
Operation
4.7 Operation with the Module R-SW
Touch Screen
• On the display, select the button for the required handpiece in the ‘Module selec-
tion’ eld, e.g.
.
ATTENTION!
Malfunction of the device or its components are possible.
• Before starting treatment, it is essential to perform the funCtiOnal CheCks
described in Chapter 4.7.3..
To activate the optional Skin Touch function:
Press
.
• In the open menu list, select the function.
• Select the option .
– The green tick indicates that Skin Touch is active.
Stand alone Version
• Switch on the DUOLITH
®
SD1 using the main switch on the rear of the column.
• Trigger shock waves by pressing the Trigger button on the handpiece (Fig. 4-3/1).
4.7.1 Setting treatment parameters
NOTE
In R-SW mode, the shock wave frequency can be selected in steps from 1 Hz to
21 Hz with energy levels of 0.3 to 5.0 bar.
The pulse frequency in V-ACTOR mode can be selected in steps up to 50 Hz at
1.0 to 5.0 bar.
Using the touch screen on the CONTROL module
• Set the treatment parameters in the PARAMETER SELECTION eld of the touch
screen by pressing the
and buttons or select an indication
(see Chapter 4.5.5 lOading indiCatiOns).
