3-9
17 363 02 0320
System description
Changing the mains voltage
• Move the switch using a pointed object (such as a at-blade screwdriver) until
the required value is under the arrowhead.
Fig. 3-9 Mains voltage set to 115 V
• Adjust the fuse value of the mains fuse according to the selected mains voltage
(see chapter 6.5 fuse replaCeMent).
Connecting the electrical power supply
• Connect the mains cable to the mains connection on the rear of the device.
1 Mains connector
1
Fig. 3-10 Mains connector
• Insert the mains cable into the electrical socket.
3.4 Transport
• Make sure there are no objects on the device.
• Remove the handpiece and, if supplied, the ultrasound probe and foot switch.
• Disconnect the mains plug.
• Remove the potential equalisation connector.
ATTENTION!
Incorrect handling during transport will damage the device!
• Only hold the device at the handle when transporting.
Do not use either the handpiece holder or the monitor for pushing or pulling
the device.
