System description
3.7 Description of the R-SW module with accessories
3.7.1 Control and functional elements
The R-SW module can be controlled in different ways, depending on the conguration.
If the device is equipped with the CONTROL module, it is operated using the touch
screen.
1
2
3
1 Touch screen
2 Checklamp
3 R-SW module
Fig. 3-28 Front of R-SW module with CONTROL
1 Mains switch
2 R-SW module
1
2
Fig. 3-29 Rear side of the DUOLITH SD1
