8-12 Sun StorEdge 3000 Family Installation, Operation, and Service Manual • May 2004
SID Secondary controller’s ID mapping:
* Multiple IDs (Host Channel mode only).
# The ID to which host LUNs are mapped in the host channel
mode. ID for the secondary controller in drive channel
mode.
NA No ID applied.
DefSynClk Default bus synchronous clock:
n GHz Maximum synchronous transfer rate.
Async Channel is set for asynchronous transfers.
DefWid Not Applicable to Fibre Channel RAID arrays.
S Signal:
S Single-ended
LLVD
F Fibre
Term Terminator status:
On Termination is enabled.
Off Termination is disabled.
NA For a redundant controller communications channel
(RCCOM).
CurSynClk Current bus synchronous clock:
xx.x MHz The current speed at which the channel is communicating.
Async. The channel is communicating asynchronously or no device
is detected.
(empty) The default bus synchronous clock has changed. Reset the
controller for changes to take effect.
CurWid Not applicable to Fibre Channel RAID array.
TABLE 8-5 Parameters Displayed in the Channel Status Table (Continued)
Parameters Description
