4-6 Sun StorEdge 3000 Family Installation, Operation, and Service Manual • May 2004
4.2.2 Sun StorEdge 3511 FC Array
FIGURE 4-4 identifies the hardware connections on the back of a dual-controller Sun
StorEdge 3511 FC array.
FIGURE 4-4 Hardware Connections on the Back of a Dual-Controller Sun StorEdge 3511 FC Array
application/data servers and consoles
FC device connections
FC expansion units/FC arrays
Management
console
Servers and consoles
FC devices
