UltraSPARC User’s Manual

ECAD<19:0> for UltraSPARC-II

ECAT<17:0> for UltraSPARC-II

LOOP_CAP present in UltraSPARC-I only

System Interface Controls

System Reply S_REPLY<3:0> 4 I

Processor Reply P_REPLY<4:0> 5 O

Address Bus Arbitration NODE_RQ<2:0> 3 I

Address Bus Request NODEX_RQ 1 O

Address Packet Valid ADR_VLD 1 I/O

SC Request for interconnect addr bus SC_RQ 1 I

SC Data Stall DATA_STALL 1 I

UDB Interface

Uncorrectable Error (High) UDB_UEH 1 I

Uncorrectable Error (Low) UDB_UEL 1 I

Correctable Error (High) UDB_CEH 1 I

Correctable Error (Low) UDB_CEL 1 I

UDB Control UDB_CNTL<4:0> 5 O

Clock Interface

Differential Clock Input A CLKA 1 I

Differential Clock Input B CLKB 1 I

PLL loop ﬁlter connection LOOP_CAP

Low Frequency/D.C. signal DC_SPARE 1 I

UDB Clock A (copy) SDBCLKA 1 I

UDB Clock B (copy) SDBCLKB 1 I

Phase Lock Loop Bypass PLLBYPASS 1 I

Level 5 Clock L5CLK 1 O

IEEE 1149.1 (JTAG) Interface/Debug

IEEE 1149.1 Test Data Out TDO 1 O

IEEE 1149.1 Test Data Input TDI 1 I

IEEE 1149.1 Test Clock Input TCK 1 I

IEEE 1149.1 Test Mode Select TMS 1 I

IEEE 1149.1 Test Reset Input TRST_L 1 I

SRAMs Test Mode RAM_TEST 1 I

Test/Debug/Instrument Bus MISC_BIDIR<14:0> 15 I/O

Clock Stopper (debug) EXT_EVENT 1 I/O

Initialization

Reset RESET_L 1 I

XIR Reset (NMI) XIR_L 1 I

Power Down Mode EPD 1 I

Table E-8 UltraSPARC Signals (Continued)

Function Name Count I/O
