Suzuki GSX-R1000K5 User Manual

CHASSIS 8-73
REAR BRAKE
CONSTRUCTION
1 Brake pedal A Caliper air bleeder valve 
2 Piston/Cup set B Brake hose union bolt ITEM N·m kgf-m lb-ft
3 Reservoir hose C Brake caliper mounting bolt A 6.0 0.6 4.5
4 Brake hose D Brake master cylinder mounting bolt B 23 2.3 16.5
5 Brake pad E Brake master cylinder rod lock-nut C 25 2.5 18.0
6 Shim F Brake caliper housing bolt D 10 1.0 7.0
7 Piston G Brake pad mounting pin E 18 1.8 13.0
8 Brake pad spring F 37 3.7 27.0
G 17 1.7 12.5
SAMPLE

Suzuki GSX-R1000K5 Specifications

General

Brand	Suzuki
Model	GSX-R1000K5
Category	Motorcycle
Language	English
