Suzuki GSX-R1000K5 - Rear Brake Hose Routing

10-26 SERVICING INFORMATION
REAR BRAKE HOSE ROUTING
*1
*2
28˚
*1
*3
*1
5˚
*2
*1 Clamp ends should face backward. *3 White paint faces topside.
*2
After the brake hose union has contacted the
stopper, tighten the union bolt.
