Page #133 background image
F100 Network Port Configuration & XL-GPS Firmware
>f100 bf
OK
BURNING FILE 192-8002.fs WITH SIZE 2096640
SEC: 94
SEC: 95
SEC: 96
SEC: 97
SEC: 98
SEC: 99
SEC: 100
SEC: 101
SEC: 102
.
.
.
SEC: 125
FILESYSTEMFLASHBURNCOMPLETED
F100 BUFP Burn FPGA Firmware
Note: See “B: Upgrading System Firmware” on page175.
F100 BUFP - Burn FPGA firmware from host to target flash
Use Serial/Network port F100 BUFP when upgrading FPGA firmware - to write the FPGA
program file selected with F100 BH to the flash memory. Prior to issuing the F100 BUFP
command, the host computer must be setup as an FTP server with the new FPGA program
file stored on the FTP server. The existence of the FPGA program file on the FTP server and
an Ethernet connection is checked when the command is issued.
To write the FPGA program to the flash, send the F100 BH command with the FTP host, file
path and name, and then send the following command:
F100 BUFP<Enter>
Prior to burning the FPGA program to the target flash, another error checking step is
performed. The new FPGA program size is checked against the designated memory sector
in the target flash. If the memory sector is not big enough to store the FPGA program, the
command will be aborted, an error message, "FILE FN, EXT (yyy BYTES) TOO LARGE
FOR PARTITIONING (zzz BYTES), LOAD ABORTED" will be displayed, and the new
program will not be loaded to the flash.
After all the requirements for burning the FPGA program are met, XL-GPS will proceed to
burn the FPGA program from the FTP host computer to the target flash by responding with
the following output string.
OK<CR><LF>
098-00116-000 Rev. A............................... Page 119 of 221
