Page #59 background image
Function Summary
5: Function Reference
Function Summary
The following summary lists all the XL-GPS functions, identifies the user interfaces from
which each one is available, and provides a brief description of the function.
Available from: K = keypad, N = Network Port (Telnet), S = Serial Port
Function
Available
From
Description
F1 Time Zone Offset
K, N, S Set the time offset for Standard and Local time
F2 12/24 Hour Format
K, N, S
Apply a 12 or 24-hour format to the Front Panel Display, to
F8, and F90.
F3 Time & Date
K, N, S
Set the time and date (when not already provided by a
reference source)
F4 Serial Port
Configuration
K, N Configure the main serial port settings
F5 Time-Quality Setup
K, N, S Set the thresholds for each of the four time quality flags
F6 Keypad Lock
K*, N, S
Lock keypad access to the XL-GPS’s functions. (When
locked, F6 is the only function available from the keypad.)
F8 Continuous Time
Once-per-Second
N, S
Output the time once-per-second (to the command
line)
F9 Time On Request N, S
Output the time when triggered (to the command
line)
F11 Time Output For-
mat
N, S Change the format of the time output by F8 and F9
F13 Time Error
K, N, S View the current estimated worst case time error
F18 Software Version
Request
K, N, S View the XL-GPS’s software version information
F42 - Multicode Output
Configuration
K, N, S
To view or set up the time-code outputs of the Multicode
Outputs
F50 GPS Receiver
LLA/XYZ Position
K, N, S
View the Latitude/Longitude/Altitude or geodetic X/Y/Z
coordinates of one or more GPS antennas.
F51 GPS Antenna
Cable Delay
K, N, S
Compensate for the delay caused by the length of the GPS
antenna cable. (Use F52 to adjust timing outputs.)
098-00116-000 Rev. A............................... Page 45 of 221
