4: User Interfaces
0-9 Enter numeric values
ENTER Enters currently displayed choice, e.g., a function or yes/confirmation to save changes
CLR Clears the current selection/choice and returns to the last saved value
TIME Displays the current time. Can also be used to exit a function without saving changes.
STATUS Displays the clock status and time. Can be used to exit a function without saving changes.
MENU Displays first item in function menu. Use UP/DOWN ARROWs to display other functions.
Keypad Examples
The following examples show how to use the keypad effectively.
To open a function using ENTER:
Press Result
ENTER Displays the FUNCTION prompt
2 Enter the function’s number (“2 in this example)
ENTER
Displays F2’s first screen, DISPLAY HOUR FORMAT: 24
HOUR
To open a function using MENU:
Press Result
MENU Displays F1 on the front panel display
UP/DOWN
ARROW
Scrolls through the list of functions
ENTER Opens the function and displays its first screen
To change the settings in a function, and not save them:
Press Result
MENU Displays F1: TIME ZONE OFFSET
ENTER Displays TIME ZONE OFFSET –08:00
UP ARROW Changes the minus sign in 08:00 to a plus in +08:00
RIGHT ARROW Moves the cursor to the right, under 0.
Page 40 of 221 .................................098-00116-000 Rev. A
