F100 – Network Port Configuration & XL-GPS Firmware
F100 – Network Port Configuration & XL-GPS Firm-
ware
F100 provides two groups of commands:
• Group 1, available through the keypad and the command line, provides access to
network port settings and hardware/Firmware status information.
• Group 2, available through the command line only, provides commands for changing
system firmware, changing NTP & SNMP parameters, changing the user
name/password, resetting the unit, and pinging other network devices.
Warning: The F100 commands have the capacity to remove the XL-GPS from the network
and disable the XL-GPS’s system firmware. Use judiciously.
Reboot Warning: Saving changes to any F100 parameter using the keypad will reboot the
XL-GPS. Some of the F100 command line commands also reboot the XL-GPS. These are
identified in the following documentation.
Group 1
You can use both the keypad and the command line interface to access the following
parameters:
• Ethernet address: XL-GPS contains a unique Ethernet or Media Access Control
(MAC) address comprised of a unique number assigned to the manufacturer, and a
unique number assigned to the unit. This is factory set and cannot be changed.
• IP Address: Sets a static Internet Protocol (IP) address for the unit.
• Subnet Mask: Sets a valid subnet-mask used in IP addressing. Subnetting allows for
the more efficient allocation of network addresses and management of network traffic.
• Default Gateway: The address of the router that handles packets addressed to IP
devices outside the local-area network.
• 10 100 BASE-T: View network port setting: 10 or AUTO.
• Remote Lockout: Enables or disables remote access through the XL-GPS’s
standard network port. Enabling Remote Lockout limits users to the front-panel
keypad or Serial I/O port.
• Flash CRC: Status - Passed or failed.
• RAM: Status - Passed or failed.
• Serial: Status - Passed or failed.
• Version Test: Status - Passed or failed
098-00116-000 Rev. A............................... Page 107 of 221
