6: Option Cards
Factory Default Jumper and Switch Settings for
Options
Options Factory Default Jumper and Switch Settings for Options
87-8108: 1, 5, 10MHz JP1-4 set to jumper position 10MHz (10MHZ)
87- 8134-1/-2: Expansion
Module
l S1-4 set to switch position 1 (10MHZ)
l J1-4 set to DC (DC OUTPUT)
87-8114: 10MHZ LPN
Option
No configurations. 10MHz only.
87-6002-XL1: Multicode
Option
l o [1-4] IRIG-B 120 (set the outputs 1-4 to IRIG-B 120)
l All Potentiometers adjusted to following for IRIG-B 120
a. LEVEL 3VP-P
b. RATIO 3:1
87-399-30: OCXO Option Main Board Jumper JP1 set to position 1-2
Page 166 of 221 .................................098-00116-000 Rev. A
