F100 – Network Port Configuration & XL-GPS Firmware
>f100 config ntp snmp get host:192.168.0.1 dir:
Host config ip 192.168.0.1 already configured
Source file /config/snmp.conf bytes read: 1275
Dest file snmp.conf bytes written: 1275
Source file /etc/ntp.conf bytes read: 1166
Dest file ntp.conf bytes written: 1166
Source file /etc/ntp.keys bytes read: 44
Dest file ntp.keys bytes written: 44
Configuration files transferred successfully!
Note: The following steps cause the XL-GPS to reboot.
Using the command line, enter the commands, replacing <IP Address> with the
workstation/FTP server’s IP address.
To move the NTP config files back onto the XL-GPS, type:
>f100 config ntp set host:<IP Address> dir:<subdir><CR>
To move the SNMP config file back onto the XL-GPS, type:
>f100 config snmp set host:<IP Address> dir:<subdir><CR>
To move the NTP and SNMP config files back onto the XL-GPS, type:
>f100 config ntp snmp set host:<IP Address> dir:<subdir>
Here’s an example of a successful SNMP and NTP config file transfer:
>>f100 config set ntp snmp host:192.168.0.1 dir:
Host config ip 192.168.0.1 already configured
Are you sure(y/N)?y
Source file snmp.conf bytes read: 1275
Dest file /config/snmp.conf bytes written: 1275
Source file ntp.conf bytes read: 1166
Dest file /etc/ntp.conf bytes written: 1166
Source file ntp.keys bytes read: 44
Dest file /etc/ntp.keys bytes written: 44
Configuration files transferred successfully!
Resetting...
After XL-GPS receives the configuration files, it reboots, and goes through the normal
startup process.
F100 J – Factory Mode Jumper
Use function F100 J command to test the state of the ‘factory mode’ jumper. A value of 1
means the jumper is installed and a value of 0 means the jumper is not. The factory mode
098-00116-000 Rev. A............................... Page 121 of 221
