Page #176 background image
6: Option Cards
10 MHz Output:
Sine Amplitude
13dBm +/- 1.5dBm into 50 W
Sine Harmonic Distortion < -30 dBc
Square Wave
TTL into 50 W
Synchronization
Phase locked to the XL-GPS's internal 10 MHz oscillator to within
10ns
Connector Female BNC
CPU-Aware No
1 MPPS Output:
Sine Amplitude
> 4.5 V into 50 W
Sine Harmonic Distortion
< 0.5 V into 50 W
Square Wave 49 to 51%
Synchronization Phase locked to the clock 10MHz to within 10ns
Connector Female BNC
CPU-Aware No
5 MPPS Output:
Output High:
> 4.5 V into 50 W
Output Low:
< 0.5 V into 50 W
Duty cycle: 45 to 55%
Synchronization Phase locked to the clock 10MHz to within 10ns
Connector Female BNC
CPU-Aware No
Page 162 of 221 .................................098-00116-000 Rev. A
