5: Function Reference
Then, during the file burning process, output strings will be displayed on the terminal to
provide status to the operator. The following is an example of a successful F100 BUFP
command execution.
BURNING FILE 184-8000.bin WITH SIZE 97652 TO PARTITION:3 SECTOR:10
FILE: 97652 BYTES, PARTITION: 393204 BYTES (24% used)
SEC: 10 RE: 0
SEC: 11 RE: 0
FLASH SUCCESSFULLY PROGRAMMED
To load the FPGA program from the target flash to the FPGA, a reboot of the XL-GPS is
required for the new FPGA program to take effect. The XL-GPS can be rebooted via power
cycle or by issuing the F100 K I L L command on the serial port interface.
F100 CONFIG Configure NTP & SNMP
Notes:
See “A: Using F100 Configuration” on page171.
NTP is an optional feature. If purchased at the same time as the XL-GPS, it comes
enabled on the system. To purchase this option after you have purchased the XL-
GPS, contact Symmetricom Sales. See “H: Sales and Customer Assistance” on
page204.
F100 CONFIG GET instructs the XL-GPS unit to transfer its NTP and SNMP configuration
files to an FTP server. After editing the NTP and SNMP configuration files on the FTP
server, the user transfers them back to the XL-GPS using the F100 CONFIG SET
command.
Open a Telnet session with the XL-GPS and enter the commands below. Replace <IP
Address> with that of the workstation/FTP Server. Leave <subdir> blank (unless you have a
specific reason for placing the files in a subdirectory of the anonymous user’s home
directory).
To get the NTP config files, type:
>f100 config ntp get host:<IP Address> dir:<subdir><CR>
To get the SNMP config file, type:
>f100 config snmp get host:<IP Address> dir:<subdir><CR>
To get both the SNMP and NTP config files, type:
>f100 config ntp snmp get host:<IP Address> dir:<subdir><CR>
Here’s an example of a successful SNMP and NTP config file transfer:
Page 120 of 221 .................................098-00116-000 Rev. A
