Page #119 background image
F90 Code Output Configuration
F90 Code Output Configuration
Use function F90 to configure the time code output format (IRIG-A, IRIG-B, IRIG-B120 IEEE
1344 or NASA 36) and modulation type (AM or DC) on the XL-GPS’s standard CODE
output.
The factory settings for F90 are IRIG-B and AM.
Although the factory configuration outputs UTC time in 24-hour format, the following can be
used to modify the code output of F90 for non-standard applications:
“F2 12/24 Hour Format” on page50 selects between a 12 or 24-hour time format.
“F69 Time Mode on page90 selects between the following timescales: Local,
Standard, GPS, UTC, and TAI.
Command Line
To display the current settings, enter:
F90<CR>
XL-GPS responds using the following format:
F90<S><CODE OUTPUT><TYPE><CR>
where:
F
= ASCII character F.
90
= function number.
<S>
= Space
<CODE
OUTPUT>
=
IRIG-A, IRIG-B,IRIG-B120 1344, NASA 36
<TYPE>
= AM, DC
<CR>
= carriage return character.
<LF>
= line feed character.
For example, enter:
F90<CR>
XL-GPS responds (example):
F90 IRIG-B AM<CR><LF>
098-00116-000 Rev. A............................... Page 105 of 221
