Symmetricom XL-GPS User Manual

Function Summary
F100 BUB – Burn
BootLoader
N, S
Upgrading system firmware: ‘burn’ the bootloader file (*.bt)
selected using F100 BH to flash memory
F100 BU – Burn
N, S
Upgrading system firmware: ‘burn’ the system firmware
file (*.bin) selected using F100 BH to flash memory
F100 BF – Burn File
System
N, S
Upgrading system firmware: ‘burn’ the file system file (*.fs)
selected using F100 BH to flash memory
F100 BUFP – Burn FPGA
Firmware
N, S
Upgrading system firmware: burn the FPGA program file
(*.bin) selected using F100 BH to the flash memory
F100 CONFIG –
Configure NTP & SNMP
N, S
Transfer the NTP and SNMP configuration files between
the XL-GPS and an FTP server for editing
F100 J – Factory Mode
Jumper
N, S
View the status of the factory mode jumper, which is used
by factory technicians. Not of interest to most end users.
F100 K I L L – Reboot
N, S Reboot the XL-GPS
F100 P – Change User
Password
N, S Change the XL-GPS password
F100 PI – PING
N, S Ping from the XL-GPS to another host on the network
F100 PN – Change User
Name
N, S Change the User Name
F108 – Oscillator
Configuration
K, N, S View the oscillator type
F110 – J1 Input (Time
Code, TIET)
K, N, S Configure the J1 input connector
F111 – J2 Output (Rate,
PPO)
K, N, S Configure the J2 output connector
F113 – J3 Input (Freq
Meas)
K, N, S Configure the J3 input connector
F117 – Factory
Configuration
K, N, S
View some of the factory settings such as the serial
number or NTP state
F119 – GPS Receiver
Configuration
K, N, S Configure and display status for the GPS Receiver
F126 – Options Key Entry
K, N, S Enable an XL-GPS option by entering a software key
098-00116-000 Rev. A............................... Page 47 of 221
