1.2.6.2.5.1 Wide angle error (long wave error, integral
nonlinearity)
This type of error is mostly caused by imperfect mechanical assembly. If the disc rotates with some play or
wobbling, this will be reflected in the measured velocity. Thus it is extremely important to produce encoder-
relevant mechanical parts with the highest precision possible.
The effect of the wide angle error can be observed in the velocity signal: a sinusoidal component will be added
to the velocity.
To inspect the effect of the wide angle error, rotate the encoder ring at a constant velocity that is a multitude
of 60 RPM (60 RPM = 1 Hz).
Since the error has a peak once or more times per mechanical revolution, the frequency of the distortion will
be a multiple of the mechanical rotation frequency (Rotations Per Second, RPS).
The multitude of this frequency indicates the origin of the error:
1 x RPS - Eccentricity of the magnetic ring axis
2 x RPS - Ovality of the magnetic ring
3-8 x RPS - mounting of the magnetic ring (for example amount of the screws used for fixing the ring)
1.2.6.2.5.2 Narrow angle error (short wave error, differential
nonlinearity, Sub Divisional Error)
The error represents distortions of a quadrature sin/cos signals inside the encoder chip. This can be caused by
improper magnetic field sensing and data processing, magnetic target imperfections and external
disturbances. The positioning of the encoder ring changes the error pattern as well. Therefore, the analogue
calibration should be repeated if the mechanical setup was changed.
A tool for calibrating the narrow angle is available in OBLAC Drives.
Important
it is of vital importance for good performance to calibrate the setup with the routine.
