3.1.9.1.38 0x2000 Command object (disabled)
Command object was used for storing and loading of the configuration from flash memory. This object is
substituted with object 0x1010 for storing and object 0x1011 for loading of the configuration. Storing of the
configuration is user triggered by entering the value "save" (LittleEndian format) in the object 0x1010,
subindex 1. Loading of the configuration loads the default configuration from the flash memory. It is
performed during initialization of the slave by entering the value "load" (LittleEndian format) in the object
0x1011, subindex 1.
Name Index:Sub Type Bit
Size
Min
Data
Max
Data
Default
Data
Unit Access PDO
Mapping
Command object
(disabled)
0x2000:0 UINT 16 0 readwrite
