Pollution Degree PD 2
Supported Motors 1 x 3-phase BLDC-Motor and 1 active
brake
Attention
Servo drives including STO-SBC module shall be used only in Pollution Degree environments class PD 2
according to IEC 61800-5-1: During normal operation only non-conductive pollution may occur,
temporarily occurring conductivity caused by condensation may only be expected when the servo drive
is out of operation.
Safe digital inputs (STO-SBC input)
Number of digital inputs 2 (dual-channel safety input for activating STO-SBC
function)
Digital input type according to IEC61131-2:2007 Type 1
Voltage range 0-60 VDC
Max. transient input voltage 80 VDC
Input voltage, logic 1 15-60 V
Input voltage, logic 0 0-5 V
Input current Max. 6 mA (@24 VDC)
Test pulse toleration (OSSD pulses) Max. 1 ms
Reverse voltage protected Yes
Allowed discrepancy between digital inputs 100 ms
See diagnostic functions
Safe brake output (SBC)
Number of digital outputs 2 (dual-channel safety output for one brake
system)
Max. output voltage Servo drive main power supply (48 VDC)
Min. output voltage 0 V
Max. current. 1 A
Max. peak current. 4 A
Note
This PWM controlled brake is configured by the same object as the regular brake.
