currents can be further increased when adding active cooling (fan).
3. Servo drive floating in ambient air
This is a reference value when not integrating the node into any structure. As SOMANET servo drives are
designed as embedded products, this situation is not recommended for both thermal and mechanical
reasons!
Attention
A similarly bad cooling situation will be created if the node is mounted to a structure with poor
thermal conductivity, in particular structures made of plastic.
* The continuous phase current given in the specsheet provided by Synapticon assumes this kind of boundary
condition with a 200 x 150 x 20 mm aluminum mounting plate.
