SYNAPTICON SOMANET Node 400 User Manual

Name Index:Sub Type Bit
Size
Options Unit Access PDO
Mapping
Sensor port 3 0x2100:3 UINT 16
None 0
BISS 1 8705
BISS 2 8706
REM 16MT 8707
REM 14 8708
Incremental 1 8709
Incremental 2 8710
HALL 1 8711
HALL 2 8712
SSI 1 8713
SSI 2 8714
A-Format 8715
readwrite
Stores the index of the object containing sensor configuration.
Name Index:Sub Type Bit
Size
Options Unit Access PDO
Mapping
Sensor port 4 0x2100:4 UINT 16
None 0
BISS 1 8705
BISS 2 8706
REM 16MT 8707
REM 14 8708
Incremental 1 8709
Incremental 2 8710
HALL 1 8711
HALL 2 8712
SSI 1 8713
SSI 2 8714
A-Format 8715
readwrite
Stores the index of the object containing sensor configuration.
Name Index:Sub Type Bit
Size
Options Unit Access PDO
Mapping
