4 Overview
CyFlow™ Ploidy Analyser | Operating Manual | October 2021
17
4 Overview
4.1 Device
NOTICE
Glass parts are fragile
Objects put on the glass top or display of the device may damage or
break the glass and do not scratch glass surfaces.
• Do not place any objects on the glass top or display of the device.
Your CyFlow™ Ploidy Analyser is a fully equipped desktop flow cytometer. The CyFlow™
Ploidy Analyser is equipped with a UV LED 365 nm emission wavelength and/or a Nd-YAG
green laser 532 nm emission line.
The CyFlow™ Ploidy Analyser is equipped with one (CY-S-3039_V1) or two (CY-S-
3039_V2 / CY-S-3039_V3) optical detectors for the detection of DAPI fluorescence (CY-S-
3039_V1) and/or Propidium Iodide fluorescence and side scattered light (CY-S-3039_V2 /
CY-S-3039_V3). The fluorescence and side scattered light is collected by a microscope
lens in an angle of 90°. The light is subdivided into two different wavelength bands by optical
filter glasses.
The device runs with an integrated computer. Data acquisition, device control, and data
analysis are controlled and performed by the software.
Figure 1: Front and left side of the device
#
Item
#
Item
1
Sample port
3
On switch
2
Ports for external devices
4
Display
