CROSS FORMA: Service & Maintenance Manual - rev. 2.1
Page 6.23
(3) Check on the correct positioning of the Receiver Board as indicated in the relevant paragraph.
(4) In order to check whether there is electromagnetic noise near the equipment, use the Text Box
Excite as detailed below. You can use one of the following cables as the connection cable
between the receiver and the Test Box: ELT-16 (0WC00518AB), CBQ-28 (0WC00390AC)
or TRM-28 (0WC00336AC).
TEST BOX
EXCITE
RECEIVER
LED
Connecting cable
The circuit switches on the LED for each heart beat and/or disturbance received. In this way, it
is possible to assess whether there is any disturbance and what produces it.
Do not move too close to the LED Display with the Test Box Excite, because it is known
that this emits interference.
