TOP 600 XT PRO
1.3.1 Assembly
Slide the equipment off the pallet onto the
floor in the position where it is to be installed.
The control panel is turned upside down. To
right it, unscrew the two upper screws and
gently extract them from the frame, taking
care not to disturb the cables.
Turn the control panel 90°, reinsert it in the
frame, and screw the two screws all the way
into the lower part.
Screw on the handgrips with an octagonal
wrench, tightening them fully.
WARNING
The equipment must be assembled
by a person with general mechanical
skills and experience.
