TOP 600 XT PRO
1) Indicates the type of fuse: F 3A,
5 x 20 mm
2) Indicates the main power
specifications: 110/230 Vac~
50/60 Hz 150 VA
3) Indicates the auxiliary socket
specifications:
75 VA
4) Illustrates the main power switch:
I = on; 0 = off
5) Indicates a device with a type B
applied part
6) Indicates reference to user’s
manual
7) Indicates compliance with the CE
directives
8) Indicates the IMQ certification
agency marking
1.3.4 Power hookup
Before connecting the equipment to the main power supply, ensure that the electrical system
is in compliance with applicable code. Check the information printed on the sticker near the
socket and on the cable:
DANGER
The wall socket must be located in a
place where the equipment can be
plugged in and unplugged easily and
safely.
The equipment switch must be set at
0 (off) when plugging it in.
Connect the power cable first to the
equipment socket and then to the wall
socket.
If possible, protect the cable from damage
by using the supplied raceways.
109-1
01327003
7
3
2
4
1
01327002
8
6
5
