21
1.3 INSTALLATION AND ASSEMBLY
1.3.2 Moving the equipment
To move the equipment off the pallet to the
floor, lift it as indicated in the illustration and
let it slide onto the ground. This procedure
must be performed by at least two persons.
DANGER
Great caution must be exercised
while moving and positioning it on the
ground, since the equipment could
lose its balance.
The equipment is equipped with mounted
front wheels. To move the equipment, you
must grasp it as shown in the illustration and
then push or pull it.
If floor conditions do not permit the use of
wheels, the equipment must be moved with
normal hoisting and moving equipment.
1.3.3 Leveling
The back feet are used for leveling:
A - screw or unscrew the feet until the frame
is horizontal
B - after adjusting, tighten the lock nuts.
108
107-1
2_Top_En.P65 30/05/2002, 13.5621
