1730–Series Checks and Adjustments
5–2
pulse, 2T bar, and modulated pulse signals, and field square wave signal),
multiburst signal, and black burst signal.
For example: NTSC TEKTRONIX 1410 with Option AA and Option AB
(modified SPG2 and TSG7), TSG3, TSG5, and TSG6.
PAL TEKTRONIX 1411 with Option AA and Option AB (modified SPG12
and TSG11), TSG13, TSG15, and TSG16.
PAL–M TEKTRONIX 1412 with Option AA and Option AB (modified
SPG22 and TSG21), TSG23, TSG25, and TSG26.
NOTE.
! #! ! "
" "! ! " !! !
" # ! ! $ !" # !
" ! !" "$ ! " ! ! "$
The 1410, 1411, and 1412 Option AB are mainframes with modified TSG7
and TSG11 Color Bar generators that provide more accurately controlled
output amplitudes.
The signal generators can be ordered with one or both options (AA and AB).
The TSG3, 13, and 23 are Modulated Staircase generators with variable
APL.
The TSG5, 15, and 25 are Pulse and Bar generators with modulated pulse
and field square wave signals.
The TSG6, 16, and 26 are Multiburst generators.
3. Sine wave generator, at least 250 kHz to 10 MHz.
For example: A TEKTRONIX SG503 Leveled Sine Wave Generator
installed in a TEKTRONIX TM500 Series Power Module.
4. Function Generator
Sine Wave frequencies: 90 Hz to 2 kHz.
Amplitude: 0.1 V to 10 V p-p when loaded by 75W.
For example: TEKTRONIX FG501A Function Generator installed in a
TEKTRONIX TM500 Series Power Module.
5. Voltmeter
Range, 0 to greater than 100 Vdc; accuracy, ±0.1%.
To Next Page
