1730–Series Installation

3–11

REAR VIEW

18.970

5.250

17.270

6.875

Mounting

Holes

Figure 3-8: The 1700F05 side-by-side rack adapter.

The rack adapter is adjustable, so the 1730-Series can be more closely aligned

with other equipment in the rack. See Figure 3-8.

1700F05

1700F06

Figure 3-9: A 1700-Series instrument mounted in a 1700F05 cabinet with a

blank front panel (1700F06) covering the unused side of the cabinet.
