Tektronix 1730 Series User Manual

1730–Series Replaceable Mechanical Parts
10–4
1730–Series (B070000 & Above)
Replaceable Mechanical Parts
Fig. &
Index
No.
Tektronix
Part No.
Serial Number
Effective Dscont
Qt
y Name & Description
Mfr.
Code
Mfr. Part No.
1–1 426–2102–00 1 FRAME,CRT:BEZEL 3L462 ORDER BY DESCR
*MOUNTING PARTS*
–2 211–0690–02 2 SCR,MACH:6–32 X 0.875,PNH,SST BLKOXD,TORX & SLOT 93907 B20–70430
*END MOUNTING PARTS*
–3 333–3304–00 1 PANEL,FRONT:LITTLE
(1730/1731 ONLY)
22670 ORDER BY DESCR
333–3483–00 1 PANEL,FRONT:1735
(1735 ONLY)
22670 ORDER BY DESCR
–4 378–0258–00 1 FLTR,CONTRASTIN:GRAY,POLYCARBONATE 80009 378–0258–00
–5 333–3300–01 1 PANEL,FRONT:1730 MAIN
(1730 ONLY)
80009 333–3300–01
333–3301–01 1 PANEL,FRONT:1731 MAIN
(1731/1731 PM ONLY)
80009 333–3301–01
333–3439–00 1 PANEL,FRONT:1735
(1735 ONLY)
22670 ORDER BY DESCR
*MOUNTING PARTS*
–6 211–0721–00 1 SCREW,MACHINE:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX 0KB01 ORDER BY DESCR
–6 211–0720–01 1 SCREW,MACHINE:6–32 X 0.5,PNH,STL,CDPL,T–15 SLOT 0KB01 ORDER BY DESCR
*END MOUNTING PARTS*
–7 ––––––––––– 1 CIRCUIT BD ASSY:FRONT PNL
(SEE A2 REPL)
*MOUNTING PARTS*
–8 211–0721–00 4 SCREW,MACHINE:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX 0KB01 ORDER BY DESCR
*END MOUNTING PARTS*
–9 426–2101–01 B069999 1 FRAME SECT,CAB:FRONT 3L462 ORDER BY DESCR
–9 426–2101–04 B070000 1 FRAME SECT,CAB:FRONT 3L462 ORDER BY DESCR
*MOUNTING PARTS*
–10 211–0721–00 4 SCREW,MACHINE:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX 0KB01 ORDER BY DESCR
*END MOUNTING PARTS*
–11 ––––––––––– 1 SWITCH,PUSH:0.4A,125VAC,W/SLDR LUG,BUTTON
W/YELLOW INDICATOR
(SEE S1 REPL)
*MOUNTING PARTS*
–12 210–0405–00 2 NUT,PLAIN,HEX:2–56 X 0.188,BRS CD PL 73743 12157–50
–13 211–0100–00 2 SCREW,MACHINE:2–56 X 0.750,PNH,STL CD PL,POZ 0KB01 ORDER BY DESCR
*END MOUNTING PARTS*
–14 ––––––––––– 1 CIRCUIT BD ASSY:MAIN
(SEE A3 REPL)
*MOUNTING PARTS*
–15 211–0721–00 8 SCREW,MACHINE:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX 0KB01 ORDER BY DESCR
*END MOUNTING PARTS*
–16 ––––––––––– 1 CIRCUIT BD ASSY:GRATICULE LIGHT
(SEE A3A1 REPL)
–17 337–3321–00 1 SHIELD,ELEC:CKT BD 85471 337–3321–00
–18 ––––––––––– 1 CIRCUIT BD ASSY:POWER
(SEE A1 REPL)
*MOUNTING PARTS*
–19 211–0721–00 B078566 7 SCREW,MACHINE:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX 0KB01 ORDER BY DESCR
–19 211–0721–00 B078567 6 SCREW,MACHINE:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX 0KB01 ORDER BY DESCR
–20 337–3796–01 1 SHIELD,ELEC:0.032 BRASS,C26000,0.5 HARD 80009 337379601
–21 211–0014–00 2 SCREW,MACHINE:4–40 X 0.5,PNH,STL CD PL,POZ 93907 ORDER BY DESCR
*END MOUNTING PARTS*
–22 131–3573–00 1 CONN,PLUG,ELEC:MALE,W/LOCKING ADAPTER 80126 B–0779
–23 337–3257–00 2 SHIELD,CKT BD:LV PWR SUPPLY 2K262 ORDER BY DESCR
–24 337–3931–00 1 SHIELD,ELEC:ALUMINUM 80009 337393100
