7–1
Section 7
Options
The standard instrument is shipped with a P31 (green) phosphor CRT installed.
If Option 74 is ordered, the instrument is shipped with a P4 (white) phosphor crt
installed. The Option 74 CRT part number is given at the end of the Replaceable
Electrical Parts list.
Any of the following power cord options can be ordered for the 1730–Series. If
no power cord option is ordered, instruments are shipped with a North American
125 V power cord and one replacement fuse.
Option A1 Universal Europe 220V/16A Locking Power Plug (power cord and
one replacement fuse)
Option A2 United Kingdom 240V/15A Power Plug (power cord and one
replacement fuse)
Option A3 Australian 240V/10A Power Plug (power cord and one replacement
fuse)
Option A4 North American 250V/18A Power Plug (power cord and one
repalcement fuse)
Option A5 Swiss 240V/6A Power Plug (power cord and one replacement fuse)
Unless otherwise specified, power cords for use in North America are UL listed
and CSA certified. Cords for use in areas other than North America are
approved by at least one test house acceptable in the country to which the
product is shipped. Power cord part numbers are shown on the pull–out in
Section 10.
Cabinets
All of the Safety and EMI tests used to qualify the 1730–Series were performed
in a cabinet. There are two optional cabinets and a dual rack adapter available
for the installation of these instruments. Only a brief description is provided
here, for more information contact a Tektronix field office or distributor.
This is a plain, silver–grey cabinet that is designed for permanent mounting. The
pattern of ventilating holes in top, bottom, and sides provides adequate air
circulation for any heat generated within the instrument. When being perma-
nently mounted, care must be taken to allow the free circulation of air to and
CRT Options
Power Cord Options
Plain Cabinet (1700F00)
