1730–Series Maintenance
6–16
4. Modification or Option Number (if applicable)
If a part has been replaced with a new or improved part, the new part will be
shipped (if it is a direct replacement). If not directly replaceable the local
Tektronix field office or representative will contact the customer concerning any
changes. After any repair, circuit readjustment may be required.
Mechanical Disassembly/Assembly
The instructions contained here are for disassembly. Re–assembly is performed
by reversing the order of the steps used to disassemble the instrument.
WARNING. Unplug Power Cord:
Before attempting any disassembly of the instrument be sure to disconnect the power
cord.
CAUTION. Rear Panel Screws:
Do not re-insert screws in the rear panel when the instrument is removed from the
cabinet.
NOTE. Screw Types:
All screws, unless otherwise noted, are TORX screws and can be removed with a T15
screwdriver tip (Tektronix part number 003-0966-00). The exception is #2
Pozidrive screws which can be removed with a #1 Pozidrive tip (003-0443-00).
1. Remove the two bezel screws. See Figure. 6-3.
2. Grasping the bottom of the bezel, pull straight out and upward. There
are two hinges at the top of the bezel that hold it in place; once the bezel is at
an approximate
45° angle with the front panel they will disengage.
3. To replace, reverse the procedure.
Bezel Removal
