1730–Series Maintenance
6–15
el indicators do not light, check indicator or Driver. If indicators blink,
check RXD Buffer (U809B) or TXD Buffer (U809C).
4. Remove the male connector from the rear–panel AUXILIARY connector
and check for blinking indicators. This step checks for shorted RXD and
TXD lines.
If lights remain on, the RXD and TXD lines are shorted together.
5. Turn off POWER. This ends the Diagnostic Procedure. When the
1730–Series is powered up again it will be operating in the normal waveform
monitor configuration.
Corrective Maintenance
NOTE. Warranty Repairs:
"
NOTE. Solder:
!
"
!
Replacement parts are available through the local Tektronix field office or
representative. However, many common electronic parts are available through
local sources. Using a local source, where possible, will eliminate shipping
delays.
Changes to Tektronix instruments are sometimes made to accommodate
improved components, as they become available, and to improve circuit
performance. Therefore, it is important to include the following information
when ordering parts:
1. Part Number
2. Instrument Type or Number
3. Serial Number
Obtaining Replacement
Parts
