1730–Series Replaceable Mechanical Parts
10–5
Fig. &
Index
No.
Mfr. Part No.
Mfr.
Code Name & Description
Qt
y
Serial Number
Effective Dscont
Tektronix
Part No.
–25 175–9872–01 1 CA ASSY,SP,ELEC:2,18 AWG,2.5 L,0–N TK2364 175–9872–01
–26 333–3305–03 B069999 1 PANEL,REAR:1730/1731/1735 80009 333–3305–03
–26 333–3305–04 B070000 B078095 1 PANEL,REAR:1730/1731/1735 80009 333–3305–04
–26 333–3305–05 B078096 1 PANEL,REAR:1730/1731/1735 80009 333–3305–04
*MOUNTING PARTS*
–27 211–0721–00 3 SCREW,MACHINE:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX 0KB01 ORDER BY DESCR
*END MOUNTING PARTS*
–28 174–0335–01 1 LEAD,ELECTRICAL:22 AWG,9.75 L,9–N 80009 174–0335–01
–29 174–0123–02 1 CABLE ASSY SP:ELEC,24,26 AWG,21.0 L, RIBBON 80009 174–0123–02
*MOUNTING PARTS*
–30 214–3903–01 2 SCREW,JACK:4–40 X 0.312 EXT THD,4–40 INT THD,0.188
HEX,STEEL,CADPLATE
0KB01 214–3903–01
*END MOUNTING PARTS*
–31 ––––––––––– 1 CIRCUIT BD ASSY:SERIAL FILTER
(SEE A11 REPL)
*MOUNTING PARTS*
–32 214–3903–01 2 SCREW,JACK:4–40 X 0.312 EXT THD,4–40 INT THD,0.188
HEX,STEEL,CADPLATE
0KB01 214–3903–01
*END MOUNTING PARTS*
–33 348–1464–00 1 MANCHET:CRT,END RUBBER MANCHET,31.5MM THK X
63MM OD,50.5 ID
80009 348–1464–00
–34 407–4395–00 1 BRACKET,CRT:BACK,0.062,AL 80009 407–4395–00
*MOUNTING PARTS*
–35 210–0457–00 2 NUT,PL,ASSEM WA:6–32 X 0.312,STL CD PL 0KB01 ORDER BY DESCR
*END MOUNTING PARTS*
–36 ––––––––––– 1 CIRCUIT BD ASSY:CRT SOCKET
(SEE A10 REPL)
–37 346–0133–00 1 STRAP,TIEDOWN,E:14.0 X 0.091,NYLON 56501 TY234M EURO
DIRECT PURCH
–38 337–4064–00 1 SHIELD,ELEC:MU–METAL CRT SHIELD,SAF CONTROLLED 80009 337–4064–00
–39 334–1379–00 1 MARKER,IDENT:MKD HI VACUUM 22670 ORDER BY DESCR
–40 386–4443–00 1 SUPPORT,SHIELD:CRT,FRONT,PLASTIC 80009 386–4443–00
–41 ––––––––––– 1 ELECTRON,TUBE:CRT,FINISHED
(SEE V1 REPL)
–42 348–0171–00 1 GROMMET,PLASTIC:BLACK,U–SHAPED,0.276 ID 0KBZ5 NA
–43 343–0916–00 B078566 1 CLAMP,LOOP:0.5 ID,NYLON 34785 029–500
–43 343–0013–00 B078567 1 CLAMP,LOOP:0.375 ID,PLASTIC 34785 029–500
–44 426–2103–07 1 FRAME,CHASSIS:CHASSIS FRAME,ALUM 80009 426–2103–07
–45 211–0720–01 B078566 2 SCREW,MACH:6–32 X 0.50,PNH,STL,TORX T–15 WITH SLOT 0KB01 211–0720–01
–45 211–0720–01 B078567 3 SCREW,MACH:6–32 X 0.50,PNH,STL,TORX T–15 WITH SLOT 0KB01 211–0720–01
–51 129–1308–00 B078567 1 SPACER,POST:6–32X0.75 HEX,STL,CAD PL 0570 4538-632-s-3
STANDARD ACCESSORIES
070–7948–05 1 MANUAL,TECH:INSTR,1730 WAVEFORM MONITOR B060000
AND UP
80009 070794805
150–0168–00 3 LAMP,INCAND:14V,0.08A,WEDGE BASE,T1.75 FOR SKT MT 55335 73W
159–0021–00 1 FUSE,CARTRIDGE:3AG,2A,250V,FAST BLOW 71400 AGC–2
–46 161–0216–00 1 CABLE ASSY,PWR:3,18 AWG,2.5M L,BLACK
(STANDARD ONLY)
80126 C7120–25M–BL
OPTIONAL ACCESSORIES
–47 161–0215–00 1 CABLE ASSY,PWR:3,0.75MU,2.5MM L,GREY 80126 0–5335–008–GY
(EUROPEAN OPTION A1 ONLY)
–48 161–0066–10 1 CA ASSY,PWR:3,0.1MM SQ,250V/10A,2.5 METER,STR,
IEC320,RCPT X 13A,FUSED UK PLUG(13A FUSE),UNIT
TK2541 ORDER BY DESCR
(UNITED KINGDOM OPTION A2 ONLY)
