1730–Series Replaceable Electrical Parts
8–6
Replaceable Electrical Parts
Component
Number
Tektronix
Part Number
Serial / Assembly Number
Effective Discontinued
Name & Description
Mfr.
Code
Mfr. Part
Number
A1 671–2890–11 B079210 CIRCUIT BD ASSY:POWER SUPPLY (1730 ONLY) 80009 671289010
A1 671–2890–11 B079467 CIRCUIT BD ASSY:POWER SUPPLY (1731 ONLY) 80009 671289010
A1 671–2890–11 B079479 CIRCUIT BD ASSY:POWER SUPPLY (1731 PM ONLY) 80009 671289010
A1 671–2890–11 B072609 CIRCUIT BD ASSY:POWER SUPPLY (1735 ONLY) 80009 671289010
A1 671–2890–11 B072606 CIRCUIT BD ASSY:POWER SUPPLY (1735 BB ONLY) 80009 671289010
A1 671–2890–12 B079211 CIRCUIT BD ASSY:POWER SUPPLY (1730 ONLY) 80009 671289010
A1 671–2890–12 B079468 CIRCUIT BD ASSY:POWER SUPPLY (1731 ONLY) 80009 671289010
A1 671–2890–12 B079480 CIRCUIT BD ASSY:POWER SUPPLY (1731 PM ONLY) 80009 671289010
A1 671–2890–12 B072610 CIRCUIT BD ASSY:POWER SUPPLY (1735 ONLY) 80009 671289010
A1 671–2890–12 B072607 CIRCUIT BD ASSY:POWER SUPPLY (1735 BB ONLY) 80009 671289010
A2 670–9388–01 CIRCUIT BD ASSY:FRONT PNL 80009 670–9388–00
A3 672–1229–14 CIRCUIT BD ASSY:MAIN (1730, 1731) 80009 672–1229–14
A3 672–1266–15 CIRCUIT BD ASSY:MAIN (1735 ONLY) 80009 672–1266–15
A3 672–0225–13 CIRCUIT BD ASSY:MAIN (1731 PM ONLY) 80009 672–0225–13
A3A1 671–1796–01 CIRCUIT BD ASSY:GRATICULE LIGHT 80009 671–1796–00
A10 671–3637–00 CIRCUIT BD ASSY:CRT SOCKET BD 80009 671363700
A11 671–3761–00 CIRCUIT BD ASSY:SERIAL FILTER 80009 671376100
A1 671–2890–11 B079210 CIRCUIT BD ASSY:POWER SUPPLY (1730 ONLY) 80009 671289010
A1 671–2890–11 B079467 CIRCUIT BD ASSY:POWER SUPPLY (1731 ONLY) 80009 671289010
A1 671–2890–11 B079479 CIRCUIT BD ASSY:POWER SUPPLY (1731 PM ONLY) 80009 671289010
A1 671–2890–11 B072609 CIRCUIT BD ASSY:POWER SUPPLY (1735 ONLY) 80009 671289010
A1 671–2890–11 B072606 CIRCUIT BD ASSY:POWER SUPPLY (1735 BB ONLY) 80009 671289010
A1 671–2890–12 B079211 CIRCUIT BD ASSY:POWER SUPPLY (1730 ONLY) 80009 671289010
A1 671–2890–12 B079468 CIRCUIT BD ASSY:POWER SUPPLY (1731 ONLY) 80009 671289010
A1 671–2890–12 B079480 CIRCUIT BD ASSY:POWER SUPPLY (1731 PM ONLY) 80009 671289010
A1 671–2890–12 B072610 CIRCUIT BD ASSY:POWER SUPPLY (1735 ONLY) 80009 671289010
A1 671–2890–12 B072607 CIRCUIT BD ASSY:POWER SUPPLY (1735 BB ONLY) 80009 671289010
A1C1 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A1C2 283–0021–00 CAP,FXD,CER DI:0.001UF,20%,5000V TK2058 TCK45YS3H102M–A
A1C3 283–0261–00 CAP,FXD,CER DI:0.01UF,20%,4000V 18796 DHR28Z5U103M4KV
A1C4 283–0261–00 CAP,FXD,CER DI:0.01UF,20%,4000V 18796 DHR28Z5U103M4KV
A1C5 285–1341–01 CAP,FXD,PLASTIC:MTLZD FILM;0.1UF,20%,100V,POLYEST TK1913 MKS 2 0.1UF 20%
A1C6 281–0771–00 CAP,FXD,CER DI:2200PF,20%,200V 04222 SA102C222MAA
A1C7 285–1470–00 CAP,FXD,PLASTIC:MTLZD FILM;330PF,1600VDC/500VAC,
POLYPROPYLENE,11 X18
TK1913 FKP1 330/1600/5
A1C8 283–0261–00 CAP,FXD,CER DI:0.01UF,20%,4000V 18796 DHR28Z5U103M4KV
A1C9 283–0261–00 CAP,FXD,CER DI:0.01UF,20%,4000V 18796 DHR28Z5U103M4KV
A1C10 281–0563–00 CAP,FXD,CERAMIC:MLC;0.47UF,20%,50V,0.150 X0.290 04222 SA305E474MAA
A1C11 283–0021–00 CAP,FXD,CER DI:0.001UF,20%,5000V TK2058 TCK45YS3H102M–A
A1C12 281–0707–00 CAP,FXD,CER DI:15000PF,10%,200V 04222 MA302C153KAA
A1C13 281–0707–00 CAP,FXD,CER DI:15000PF,10%,200V 04222 MA302C153KAA
A1C14 281–0707–00 CAP,FXD,CER DI:15000PF,10%,200V 04222 MA302C153KAA
A1C15 285–1341–01 CAP,FXD,PLASTIC:MTLZD FILM;0.1UF,20%,100V,POLYEST TK1913 MKS 2 0.1UF 20%
A1C16 290–1311–00 CAP,FXD,ALUM:10UF,20%,50V,ESR=1.4 OHM
(100KHZ,20C),5X11MM,105C,5000HRS
55680 UPL1H100MDH1TD
A1C17 285–1341–01 CAP,FXD,PLASTIC:MTLZD FILM;0.1UF,20%,100V,POLYEST TK1913 MKS 2 0.1UF 20%
A1C18 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A1C19 290–1310–00 CAP,FXD,ALUM:10UF,20%,160V,ESR=24.9 OHM
(120HZ,20C),LS=0.200 INCH,13X20MM,105C,5000HRS
0H1N5 CEJSM2C100M
A1C20 281–0707–00 CAP,FXD,CER DI:15000PF,10%,200V 04222 MA302C153KAA
