Tektronix Keithley 4225-PMU User Manual

Model 4200A
-SCS Pulse Card (PGU and PMU) User's Manual Section 2:
Connections
4200A-PMU-900-01 Rev. B March 2023 2-21
Offset current compensation
Error currents can be introduced into your pulsed measurements setup by PMUs. PMU offset
compensation reduces error currents by subtracting measurements taken at 0 V from all
subsequent readings.
Perform connection compensation
To compensate for connections:
1. In Clarius, select Tools. The Clarius Tools dialog opens.
Figure 20: Clarius Tools dialog
2. Select PMU Connection Compensation. The Short and Offset Current Connection
Compensation Values and Defaults dialog opens.
3. From the PMU list, select the PMU that you want to perform compensation for.
