Tektronix TDS5000B Series Service Manual

Mechanical Parts List
10- 10
TDS5000B Series Service Manual
Modules (Cont.)
Fig. &
index
number
Mfr. part number
Mfr.
code
Name & descriptionQty
Serial no.
discont’d
Serial no.
effective
Tektronix part
number
--26 119--6441--00 2 FAN,TUBEAXIAL:12VDC,0.15A,1.8W,48CFM, 2450RPM,30DBA,
92MM X 92MM X 26MM, W/ 7IN LEADS & CONNECTO
61058 FBA09A12M
--27 174--4531--00 1 CABLE:PRINTER 1DM20 174 --4531--00
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
7
7
7
18
19
20
21
22
23
24
25
26
27
See Fig 10--5
Figure 10- 3: Modules
