Mechanical Parts List
TDS5000B Series Service Manual
10- 13
Acquisition assembly
Fig. &
index
number
Tektronix
part number
Serial no.
effective
Serial no.
discontd
Qty Name & description
Mfr.
code
Mfr. part number
5--1 671--5738--00 1 C KT BD SUBASSY:ACQUISITI ON, TDS5104 80009 671--5738--00
671--5739--00 1 CKT BD SUBASSY:ACQUISITION, TDS5054, TDS5034B,
TDS5054BE
80009 671--5739--00
671--5740--00 1 CKT BD SUBASSY:ACQUISITION, TDS5052, TDS5032B 80009 671--5740--00
--2 211--1050--00 6 SCREW,MACHINE:6--32 X 0.312 L,PNH,STL CAD,T15 0KB01 OBD
--3 174--2729--00 1 CABLE ASSY:COAX,RFP,50 OHM,5.5 L,PELTOLA BOTH ENDS 060D9 174--2729--00
--4 174--2637--00 1 CABLE ASSY:,RF,50 OHM COAX,7.0 L,,PELTOLA BOTH ENDS 060D9 174--2637--00
--5 175--8029--00 1 CABLE ASSY,RF:50 OHM COAX,12.0 L,PELTOLA X PELTOLA 060D9 175--8029--00
--6 131--1315--01 3 CONN,RF JACK:BNC/PNL,50 OHM PELTOLA/REAR PNL,
WITH HARDWARE
24931 28JR306--1
--7 174--4483--00 1 CABLE ASSY:FLEX,20 COND,PROBE INTERFACE 1DM20 174 --4483--00
--8 679--5209--00 1 CKT BD SUBASSY:PROBE INTERFACE 80009 679--5209--00
