User Manual for Oscar GNSS Receiver v2.4

103

Figure 4.9 Link status of base using internal radio

4.2Rover operation

Figure 4.10 Oscar as a Rover - Network Mode

Table 4.4 Devices of Oscar as a rover network mode

NO.

Device Name

Oscar GNSS receiver

Ranging pole

Bracket for TC20/TC50

TC20/TC50 Controller
