User Manual for Oscar GNSS Receiver v2.4

2.8Operations of TC50 controller

2.8.1Insert SIM card and SD card

Please note the direction of the card notch when inserting the card, inserting a

non-standard card may cause damage to the SIM card slot of the controller.

The controller cannot support two CDMA cards at the same time, when two

CDMA cards are installed at the same time, only one card can use the 4G

network, the other card will not be able to register the network.

To install the SIM card you need to open the battery cover, remove the battery

and open the SIM card cover.

Note: Please power off the controller before plug in or pull out the SIM card.
