User Manual for Oscar GNSS Receiver v2.4

Figure 1.23 Bullet-DC to Alligator Clips

1.3.6 Other accessories

Other accessories may be packed according to customer requirements.

The GNSS antenna connector is used to install Oscar to a tripod.

Figure 1.24 GNSS antenna connector

The height measure accessory is used to determine the height of Oscar with

higher accuracy.

Figure 1.25 Height measure accessory
